Standardni manometer, priklop zadaj, G 1/4, 0 - 25 bar, Ø 50
SKU: 101743RIE
EAN: 12393798
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0 - 25 bar, Ø 50
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Čas dobave: Predvidoma 3 - 5 dni
12,64 €
| Šifra | Merilno območje min. bar | Povezava | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Merilno območje max. bar | Razred točnosti | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 101811RIE | 0 | G 1/8 | Positive pressure | 0.05 | 1 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € |  | |
| 101756RIE | 0 | G 1/4 | Positive pressure | 1 | 25 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101755RIE | 0 | G 1/4 | Positive pressure | 0.5 | 16 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101750RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1.6 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101745RIE | 0 | G 1/4 | Positive pressure | 2 | 60 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101744RIE | 0 | G 1/4 | Positive pressure | 2 | 40 | 2.5 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101733RIE | 0 | G 1/8 | Positive pressure | 1 | 25 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101732RIE | 0 | G 1/8 | Positive pressure | 0.5 | 16 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101743RIE | 0 | G 1/4 | Positive pressure | 1 | 25 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101734RIE | 0 | G 1/8 | Positive pressure | 2 | 40 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101759RIE | 0 | G 1/4 | Positive pressure | 5 | 100 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101730RIE | 0 | G 1/8 | Positive pressure | 0.2 | 6 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101758RIE | 0 | G 1/4 | Positive pressure | 2 | 60 | 1.6 | 63 | Na zalogi | 14,88 € | | |
| 101747RIE | -1 | G 1/4 | Vacuum | 0.05 | 0 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101741RIE | 0 | G 1/4 | Positive pressure | 0.5 | 10 | 1.6 | 50 | Na zalogi | 12,64 € | | |
| 101752RIE | 0 | G 1/4 | Positive pressure | 0.2 | 4 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101753RIE | 0 | G 1/4 | Positive pressure | 0.2 | 6 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101727RIE | 0 | G 1/8 | Positive pressure | 0.05 | 1.6 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101737RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1.6 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101763RIE | 0 | G 1/4 | Positive pressure | 20 | 400 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101738RIE | 0 | G 1/4 | Positive pressure | 0.1 | 2.5 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101761RIE | 0 | G 1/4 | Positive pressure | 10 | 250 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101740RIE | 0 | G 1/4 | Positive pressure | 0.2 | 6 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101762RIE | 0 | G 1/4 | Positive pressure | 10 | 315 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101736RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101746RIE | 0 | G 1/4 | Positive pressure | 5 | 100 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,88 € | | |
| 101749RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101760RIE | 0 | G 1/4 | Positive pressure | 5 | 160 | 1.6 | 63 | Na zalogi | 14,88 € | | |
| 101754RIE | 0 | G 1/4 | Positive pressure | 0.5 | 10 | 1.6 | 63 | Na zalogi | 12,64 € | | |
| 101735RIE | -1 | G 1/4 | Vacuum | 0.05 | 0 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101742RIE | 0 | G 1/4 | Positive pressure | 0.5 | 16 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101739RIE | 0 | G 1/4 | Positive pressure | 0.2 | 4 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101751RIE | 0 | G 1/4 | Positive pressure | 0.1 | 2.5 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101729RIE | 0 | G 1/8 | Positive pressure | 0.2 | 4 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101757RIE | 0 | G 1/4 | Positive pressure | 2 | 40 | 1.6 | 63 | Na zalogi | 12,64 € | | |
| 101731RIE | 0 | G 1/8 | Positive pressure | 0.5 | 10 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101748RIE | 0 | G 1/4 | Positive pressure | 0.02 | 0.6 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 12,64 € | | |
| 101726RIE | -1 | G 1/8 | Vacuum | 0.05 | 0 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | | |
| 101728RIE | 0 | G 1/8 | Positive pressure | 0.1 | 2.5 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 12,36 € | |
Opis
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0 - 25 bar, Ø 50
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Tehnični podatki in specifikacije
| Povezava | G 1/4 |
| Položaj povezave | rear, centrical |
| Premer [mm] | 50 |
| Vrsta | 111.12 |
| Razred točnosti | 1.6 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 60 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Ohišje | Plastic |
| Merilni element | Copper alloy |
| Premikanje | Copper alloy |
| Prednje steklo | Transparent plastic |
| Merilno območje max. bar | 25 |
| Stopnja rasti na območju skale - bar [bar] | 1 |
| Spodnja/Zgornja meja območja | Positive pressure |
| Material Prozessanschluss | Copper alloy |
