* slike so simbolične
Nav. koleno 90, 90°, N.N./N.N.Rp 1/2,č. kovanlit. ž.
SKU: 112891RIE
EAN: 4047322252072
Bracket 90, 90°, IT/IT, Rp 1/2, Operating temp. -20°C to 300°C, black malleable cast iron, Hot-dip galvanised, DIN EN 10242
"Acc. to DIN EN 10242 (formerly DIN 2950)
The classic - and the most popular - screw fitting series for pipe construction.
These fittings are characterized by their high mechanical strength and surface quality to DIN 2444.
They are completely coated with a layer of pure zinc and are therefore suitable for drinking water
| Šifra | Navoj | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|
| 112894RIE | Rp 1 1/4 | Čas dobave: Predvidoma 3 - 5 dni | 6,53 € |  | |
| 112889RIE | Rp 1/4 | Čas dobave: Predvidoma 3 - 5 dni | 2,37 € | | |
| 112897RIE | Rp 2 1/2 | Čas dobave: Predvidoma 3 - 5 dni | 32,66 € | | |
| 112896RIE | Rp 2 | Čas dobave: Predvidoma 3 - 5 dni | 12,47 € | | |
| 112890RIE | Rp 3/8 | Čas dobave: Predvidoma 3 - 5 dni | 2,26 € | | |
| 112898RIE | Rp 3 | Čas dobave: Predvidoma 3 - 5 dni | 47,17 € | | |
| 112895RIE | Rp 1 1/2 | Čas dobave: Predvidoma 3 - 5 dni | 10,17 € | | |
| 112892RIE | Rp 3/4 | Čas dobave: Predvidoma 3 - 5 dni | 2,51 € | | |
| 112893RIE | Rp 1 | Čas dobave: Predvidoma 3 - 5 dni | 3,82 € | | |
| 112891RIE | Rp 1/2 | Čas dobave: Predvidoma 3 - 5 dni | 1,71 € | |
Opis
Bracket 90, 90°, IT/IT, Rp 1/2, Operating temp. -20°C to 300°C, black malleable cast iron, Hot-dip galvanised, DIN EN 10242
"Acc. to DIN EN 10242 (formerly DIN 2950)
The classic - and the most popular - screw fitting series for pipe construction.
These fittings are characterized by their high mechanical strength and surface quality to DIN 2444.
They are completely coated with a layer of pure zinc and are therefore suitable for drinking water
Tehnični podatki in specifikacije
| Min. temperaturno območje [°C] | -20 |
| Max. temperaturno območje [°C] | 300 |
| Material | Black malleable iron B350-10, design symbol A |
| Površina | Hot dip galvanised |
| Navoj | Rp 1/2 |
| Standardni navoj | acc. ISO 7-1 |
