Kamlok hitra spojka, zunanji navoj, F tip, Alu, R 1 1/2
SKU: 108061RIE
EAN: 4047322403498
Kamlok quick-connect plug with exterior thread, F type, Aluminium, R 1 1/2, Plug Ø 53 mm, Pressure max. 16 bar, Temp. max. 68 °C
Coupling system for quick and easy connection of two hoses or for joining one hose to a machine connection.
A male part and a female part are joined together by shifting the handles.
There is no need to turn the hose!
Kamlok couplings are used for a wide range of applications in industrial plant and mechanical engineering, tank and container construction, the chemical industry, food processing, mining, refuelling systems, defence technology, etc.
| Šifra | Navoj | Vtič Ø [mm] | L [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|
| 108063RIE | R 2 1/2 | 76 | 97.0 | Čas dobave: Predvidoma 3 - 5 dni | 15,87 € |  | |
| 108059RIE | R 1 | 37 | 67.8 | Čas dobave: Predvidoma 3 - 5 dni | 6,36 € | | |
| 108061RIE | R 1 1/2 | 53 | 76.0 | Čas dobave: Predvidoma 3 - 5 dni | 7,93 € | | |
| 108065RIE | R 4 | 120 | 104.5 | Čas dobave: Predvidoma 3 - 5 dni | 33,83 € | | |
| 108060RIE | R 1 1/4 | 45 | 78.0 | Čas dobave: Predvidoma 3 - 5 dni | 7,12 € | | |
| 108058RIE | R 3/4 | 32 | 55.0 | Čas dobave: Predvidoma 3 - 5 dni | 4,97 € | | |
| 108062RIE | R 2 | 63 | 83.5 | Čas dobave: Predvidoma 3 - 5 dni | 10,93 € | | |
| 108064RIE | R 3 | 92 | 99.5 | Čas dobave: Predvidoma 3 - 5 dni | 21,03 € | |
Opis
Kamlok quick-connect plug with exterior thread, F type, Aluminium, R 1 1/2, Plug Ø 53 mm, Pressure max. 16 bar, Temp. max. 68 °C
Coupling system for quick and easy connection of two hoses or for joining one hose to a machine connection.
A male part and a female part are joined together by shifting the handles.
There is no need to turn the hose!
Kamlok couplings are used for a wide range of applications in industrial plant and mechanical engineering, tank and container construction, the chemical industry, food processing, mining, refuelling systems, defence technology, etc.
Tehnični podatki in specifikacije
| Navoj | R 1 1/2 |
| Max. obratovalni tlak [bar] | 16 |
| Vtič Ø [mm] | 53 |
| Min. temperaturno območje [°C] | -20 |
| Max. temperaturno območje [°C] | 68 |
| Tesnilo | NBR, resistant to oils and benzine |
| L [mm] | 76.0 |
